AM3+ Socket: - AMD AM3+ FX processors
- AMD AM3 Phenom™ II processor/ AMD Athlon™ II processor
(Please refer 'CPU Support List' for more information.) |
| Hyper Transport Bus | - HyperTransport™ 3.0
- Support up to 5200MT/s
|
| Chipset | - North Bridge: AMD 970
- South Bridge: AMD SB950
|
| Memory | - 4 x DDR3 DIMM sockets supporting up to 32 GB of system memory (Note 1)
- Dual channel memory architecture
- Support for DDR3 2000(O.C.)/1866/1600/1333/1066 MHz memory modules (Note 2)
(Please refer 'Memory Support List' for more information.) |
| Audio | - Realtek® ALC887 audio codec
- High Definition Audio
- 2/4/5.1/7.1-channel
- Support for S/PDIF Out
|
| LAN | - Realtek® GbE LAN chip (10/100/1000 Mbit)
|
| Expansion Slots | - 1 x PCI Express x16 slot, running at x16 (PCIEX16) (Note 3)
- 1 x PCI Express x16 slot, running at x4 (PCIEX4)
- 3 x PCI Express x1 slots
(All PCI Express slots conform to PCI Express 2.0 standard.) - 2 x PCI slots
|
| Storage Interface | South Bridge: - 6 x SATA 6Gb/s connectors
- Support for RAID 0, RAID 1, RAID 5, RAID 10, and JBOD
|
| USB | South Bridge: - 12 x USB 2.0/1.1 ports (6 ports on the back panel, 6 ports available through the internal USB headers)
VIA® VL805 chip: - 4 x USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB header)
|
| Internal I/O Connectors | - 1 x 24-pin ATX main power connector
- 1 x 4-pin ATX 12V power connector
- 6 x SATA 6Gb/s connectors
- 1 x CPU fan header
- 2 x system fan headers
- 1 x power fan header
- 1 x front panel header
- 1 x front panel audio header
- 1 x S/PDIF Out header
- 1 x USB 3.0/2.0 header
- 3 x USB 2.0/1.1 headers
- 1 x Clear CMOS jumper
|
| Back Panel Connectors | - 1 x PS/2 keyboard port
- 1 x PS/2 mouse port
- 2 x USB 3.0/2.0 ports
- 6 x USB 2.0/1.1 ports
- 1 x RJ-45 port
- 3 x audio jacks (Line In/Line Out/Microphone)
|
| I/O Controller | - iTE® I/O Controller Chip
|
| H/W Monitoring | - System voltage detection
- CPU/System temperature detection
- CPU/System/Power fan speed detection
- CPU overheating warning
- CPU/System/Power fan fail warning
- CPU/System fan speed control (Note 4)
|
| BIOS | - 2 x 32 Mbit flash
- Use of licensed AMI UEFI BIOS
- Support for DualBIOS™
- PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
|
| Unique Features | - Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
@BIOS
Ambient LED
Cloud Station
EasyTune
Game Controller
Smart TimeLock
Smart Recovery 2
System Information Viewer
USB Blocker - Support for Q-Flash
- Support for ON/OFF Charge
- Support for Smart Switch
- Support for Xpress Install
|
| Bundle Software | - Norton Internet Security (OEM version)
- cFosSpeed
|
| Operating System | - Support for Windows 10/8.1/7 32-bit/64-bit
|
| Form Factor | - ATX Form Factor; 30.5cm x 21.5cm
|
| Note | (Note 1) Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
(Note 2) To support a DDR3 1866 MHz (and above) memory, you must install an AM3+ CPU first.
(Note 3) For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
(Note 4) Whether the fan speed control function is supported will depend on the cooler you install. |
| Remark | - Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
- Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP SP1/SP2. If drivers are available from the vendors, we will update them on the GIGABYTE website.
|
